QNAP ES1640dc NAS Rack (3U) Intel® Xeon® E5 v2 familie E5-2420V2 DDR3 0 TB QNAP QES Zwart

QNAP ES1640dc, NAS, Rack (3U), Intel® Xeon® E5 v2 familie, E5-2420V2, DDR3, 0 TB

Niet op voorraad

Fabrikant QNAP
MPN ES1640DC-V2-E5-96G
EAN 4713213510544
€ 14.476,00 excl. BTW

QNAP ES1640dc NAS Rack (3U) Intel® Xeon® E5 v2 familie E5-2420V2 DDR3 0 TB QNAP QES Zwart

QNAP ES1640dc-v2-E5-96G NAS 16-Bay [0/16 HDD/SSD, 6x 10GbE LAN, 96GB RAM]

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Opslagmedia

Capaciteit opslag-drive*
0 GB
Opslag schijf-interface*
Serial Attached SCSI (SAS)
Opslag schijfgrootte
2.5/3.5"
Maximaal ondersteunde opslagcapaciteit
128 TB
RAID support*
Ja
Opslagdrives geïnstalleerd*
Nee
Totale geïnstalleerde opslagcapaciteit*
0 TB
Aantal storage drives ondersteund*
16
Geïnstalleerde opslag-drive*
Nee
Ondersteunde types opslag-drives*
HDD & SSD

Processor

Processorfabrikant*
Intel
Processorfamilie*
Intel® Xeon® E5 v2 familie
Processormodel*
E5-2420V2
Frequentie van processor*
2,2 GHz
Maximale turbofrequentie van processor
2,7 GHz
Aantal processorkernen
6
Processor aantal threads
12
Processor cache
15 MB
L3 cache
15 MB
Bus type
QPI
CPU configuratie (max)
2
ECC ondersteund door processor
Ja
PCI Express slots versie
3.0
Physical Address Extension (PAE)
46 Bit
Processor cache type
Smart Cache
Processorcode
SR1AJ
Codenaam processor
Ivy Bridge EN
Processor lithografie
22 nm
Processor operating modes
64-bit
Verpakkingsgrootte processor
45 x 42.5 mm
Processor socket
LGA 1356 (Socket B2)
Schaalbaarheid
2S
Stepping
S1
Systeembus
7,2 GT/s
Tcase
76 °C
Thermal Design Power (TDP)
80 W
Maximaal intern geheugen ondersteund door processor
384 GB
Geheugenbandbreedte ondersteund door de processor ( max)
38,4 GB/s
Conflictvrije processor
Nee

Geheugen

Intern geheugentype
DDR3
Geheugenslots
6
Flash memory
2000 MB

Netwerk

Ethernet LAN*
Ja
Ethernet LAN, data-overdrachtsnelheden
10,100,1000,10000 Mbit/s
Wifi
Nee

Poorten & interfaces

USB-poort*
Ja
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A
2
Vezel-optische connector
SFP+
Aantal Ethernet LAN (RJ-45)-poorten*
2

Design

Type behuizing*
Rack (3U)
Type koeling*
Actief
Kleur van het product
Zwart
Aantal ventilatoren
3 ventilator(en)

Prestatie

Soort*
NAS
Apparaatklasse*
Kleine & middelgrote bedrijven
Geluidsniveau
66,1 dB

Software

Inclusief besturingssysteem*
QNAP QES

Energie

Vermogenstoevoer locatie
Ingebouwd
Capaciteit voedingsunit (PSU)
770 W
Stroomverbruik (typisch)
501,4 W
Slaapstand
314,86 W

Gewicht en omvang

Breedte*
446,2 mm
Diepte*
618 mm
Hoogte*
132 mm
Gewicht
26,8 kg
Gewicht verpakking
36,9 kg

Processor speciale functies

Ingebouwde opties beschikbaar
Nee
Enhanced Intel SpeedStep Technology
Ja
Execute Disable Bit
Ja
Idle States
Ja
Intel® 64
Ja
Intel® Demand Based Switching
Ja
Intel® Enhanced Halt State
Ja
Intel® Flex Memory Access
Nee
Versie Intel® Identity Protection Technology
0,00
Versie Intel® Secure Key Technology
1,00
Intel® Trusted Execution Technology
Ja
Intel® TSX-NI
Nee
Versie Intel® TSX-NI
0,00
Intel® Virtualization Technology (VT-x)
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Ja
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® AES New Instructions (Intel® AES-NI)
Ja
Intel® Hyper Threading Technology (Intel® HT Technology)
Ja
Intel® Identity Protection Technology (Intel® IPT)
Nee
Intel® OS Guard
Ja
Intel® Secure Key
Ja
Intel® Smart Cache
Ja
Intel® Turbo Boost Technology
2.0
Maximaal aantal PCI Express-lijnen
24
aantal QPI links
1
Physical Address Extension (PAE)
Ja
Thermal Monitoring Technologies
Ja
Geheugenkanalen ondersteund door processor
Trippel
Geheugentypen ondersteund door processor
DDR3-SDRAM

Overige specificaties

ARK ID processor
75784
