ICY BOX IB-DK2102-C Bedraad USB 3.2 Gen 1 (3.1 Gen 1) Type-C Antraciet, Zwart

ICY BOX IB-DK2102-C, Bedraad, USB 3.2 Gen 1 (3.1 Gen 1) Type-C, 100 W, 3,5 mm, 10,100,1000 Mbit/s, Antraciet, Zwart

Ruim op voorraad

Fabrikant RaidSonic
MPN IB-DK2102-C
EAN 4250078167129
€ 61,00 excl. BTW

ICY BOX IB-DK2102-C Bedraad USB 3.2 Gen 1 (3.1 Gen 1) Type-C Antraciet, Zwart

Connection desires
Notebooks and other mobile computers are getting ever smaller but this comes at the expense of connectivity. The DockingStation IB-DK2102-C can permanently alleviate the lack of connection. 3x USB 3.0, 1x Gigabit LAN, 1x DisplayPort™, 1x HDMI®,1x VGA, 1x USB Type-C™ PD 2.0, 1x SD & microSD card reader and a headphone combo jack are provided.

Totally visual
Three different video interfaces are available, where two monitors can be operated at the same time. They enable you to connect a Mini DP and HDMI® or Mini DP and VGA device simultaneously.

The perfect position
The perfect symbiosis of stylish appearance, the latest technology, and compact size. The high-grade aluminum housing is not only appealing, but also offers comfortable access to the most important expansion ports and, thanks to its shape, at the same time, can serve as a riser for the notebook.
  • CONNECTION VERSATILITY: Supports 3x Type-A USB 3.0, 1x HDMI, 1x VGA, 1x Mini DisplayPort, 1x card reader for SD/microSD cards, 1x Gigabit LAN RJ45, 1x audio input/output and a USB Type-C charging port
  • ERGONOMIC: The shape of the docking station was created especially for laptops so that you can place them on the rear edge. This provides an ergonomic angle for typing and efficient cooling
  • POWER DELIVERY: The Type-C connector of the docking station serves as a pure charging port (no data transfer) with a power of up to 100 W (20 V@5 A). A power supply unit must be connected to the laptop for this function
  • PLUG & PLAY: The integrated Type-C cable allows users to turn their laptop into a multi-display workstation without the need to install any drivers
  • VIDEO RESOLUTION: HDMI & Mini DisplayPort up to 3840x2160@30 Hz. VGA up to 1920x1200@60 Hz. Simultaneous video output from Mini DP & HDMI or Mini DP & VGA (2x 1920x1080@60 Hz)

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Poorten & interfaces

Connectiviteitstechnologie*
Bedraad
Hostinterface*
USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A*
3
Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C
1
USB Power Delivery
Ja
USB Power Delivery tot max.
100 W
Aantal HDMI-poorten*
1
VGA (D-Sub)poort(en)
1
Mini DisplayPort kwantiteit
1
Microfoon, line-in ingang*
Nee
Combo koptelefoon/microfoon port
Ja
Hoofdtelefoonuitgangen*
1
Type aansluitplug
3,5 mm

Netwerk

Ethernet LAN*
Ja
Aantal Ethernet LAN (RJ-45)-poorten
1
Ethernet LAN, data-overdrachtsnelheden
10,100,1000 Mbit/s

Prestatie

Geïntegreerde geheugenkaartlezer*
Ja
Compatibele geheugenkaarten
MicroSD (TransFlash), SD
Overdrachtssnelheid
5 Gbit/s
HD type
4K Ultra HD
Resolutie (maximum digitaal)
3840 x 2160 Pixels
Resolutie (maximum analoog)
1920 x 1200 Pixels
Aantal displays ondersteund
3
Kleur van het product*
Antraciet, Zwart
LED-indicatoren
Ja
UASP-ondersteuning
Ja
Rubberen voetjes
Ja
Materiaal behuizing
Aluminium, Kunststof
Land van herkomst
China

Energie

Type stroombron
USB
Spanning
5 V
Output current
1,5 A

Software

Ondersteunt Windows
Windows 10
Ondersteunt Mac-besturingssysteem
Ja

Gewicht en omvang

Breedte
280 mm
Diepte
80 mm
Hoogte
18 mm
Gewicht
250 g

Verpakking

Aantal per verpakking
1 stuk(s)
Breedte verpakking
130 mm
Diepte verpakking
25 mm
Hoogte verpakking
340 mm
Gewicht verpakking
370 g

Inhoud van de verpakking

Gebruikershandleiding
Ja

Logistieke gegevens

Hoeveelheid per (buitenste) hoofdverpakking
20 stuk(s)
(Buitenste) hoofdverpakking breedte
280 mm
(Buitenste) hoofdverpakking lengte
420 mm
(Buitenste) hoofdverpakking hoogte
300 mm
(Buitenste) hoofdverpakking brutogewicht
8,5 kg
Code geharmoniseerd systeem (HS)
84733020

Overige specificaties

Snoerlengte
0,15 m
Chipset
VL100, VL812, RLT8153, STDP4320
