Specificaties
Ontwerp
Rack-montage | Ja |
---|---|
Formaat | 1U |
Aantal ventilatoren | 2 ventilator(en) |
Ingebouwde ventilator | Ja |
Data-uitwisseling
Firewall throughput | 28000 Mbit/s |
---|---|
VPN throughput | 15000 Mbit/s |
IPS/IDS throughput | 17000 Mbit/s |
Maximum firewall verbindingen per seconde | 228000 |
SSL-inspectie doorvoercapaciteit | 7000 Mbit/s |
Maximumaantal verbindingen (DPI) | 3500000 |
Maximumaantal verbindingen (SPI) | 5000000 |
VoIP | Ja |
Netwerk
VPN tunnels quantity | 6000 |
---|---|
Local user database | 2500 |
Aantal VLANs | 512 |
Quality of Service (QoS) | Ja |
Gelijktijdige SSL/VPN-verbindingen (standaard) | 350000 |
Aantal LAN Access Points (max) | 512 |
Poorten & interfaces
Connectiviteitstechnologie | Bedraad |
---|---|
Aantal Ethernet LAN (RJ-45)-poorten | 24 |
Aantal moduleslots SPF+ | 6 |
Aantal consolepoorten | 1 |
Aantal poorten USB 3.0 (3.1 Gen 1) Type A | 2 |
Protocollen
Ondersteunde netwerkprotocollen | BGP4, OSPF, RIPv1/v2, static routes, policy-based routing |
---|
Beveiliging
Ondersteunde beveiligingsalgoritmen | 3DES, 64-bit AES, 128-bit AES, 256-bit AES, DES, MD5, SHA-1 |
---|---|
Content filtering | HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists |
Advanced persistent threat (APT) detectie | Ja |
Energie
AC invoer voltage | 100-240 V |
---|---|
AC invoer frequentie | 50/60 Hz |
Voeding | 350 W |
Vermogensverbruik (max) | 128,1 W |
Opslagmedia
Totale opslagcapaciteit | 128 GB |
---|
Prestatie
Warmtedissipatie | 436,82 BTU/h |
---|---|
Certificering | FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, NATEL, BSMI |
Eisen aan de omgeving
Temperatuur, in bedrijf | 0 - 40 °C |
---|---|
Temperatuur bij opslag | -40 - 70 °C |
Relatieve luchtvochtigheid, in bedrijf | 0 - 90 procent |
Gewicht en omvang
Gewicht | 7,8 kg |
---|---|
Breedte | 430 mm |
Diepte | 465 mm |
Hoogte | 45 mm |
Verpakking
Gewicht pakket | 13,5 kg |
---|
Technische details
Code geharmoniseerd systeem (HS) | 85176990 |
---|
