Specificaties
Ontwerp
Rack-montage | Ja |
---|---|
Formaat | 1U |
Ingebouwd display | Nee |
Data-uitwisseling
Firewall throughput | 5500 Mbit/s |
---|---|
IPSec-VPN-doorvoercapaciteit | 2,1 Gbit/s |
SSL-inspectie doorvoercapaciteit | 800 Mbit/s |
Maximumaantal verbindingen (DPI) | 500000 |
HTTPS-encryptie | Ja |
VoIP | Ja |
Netwerk
VPN tunnels quantity | 250 |
---|---|
Local user database | 250 |
DHCP server | Ja |
Aantal VLANs | 256 |
DHCP client | Ja |
Quality of Service (QoS) | Ja |
Aantal LAN Access Points (max) | 32 |
Poorten & interfaces
Connectiviteitstechnologie | Bedraad |
---|---|
Aantal Ethernet LAN (RJ-45)-poorten | 16 |
Aantal moduleslots SPF+ | 3 |
Ethernet LAN, data-overdrachtsnelheden | 1000,10000 Mbit/s |
Console port | RJ-45 |
Op afstand bediende managementpoort | RJ-45 (Gigabit) |
Aantal consolepoorten | 1 |
Aantal poorten USB 3.0 (3.1 Gen 1) Type A | 2 |
Protocollen
Routing protocols | BGP, BGP4, OSPF, RIP, RIP-1, RIP-2 |
---|---|
Ondersteunde netwerkprotocollen | TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3 |
Beveiliging
Ondersteunde beveiligingsalgoritmen | 3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SHA-1 |
---|
Beheerfuncties
LED-indicatoren | Ja |
---|
Energie
AC invoer voltage | 100-240 V |
---|---|
AC invoer frequentie | 50/60 Hz |
Voeding | 60 W |
Vermogensverbruik (max) | 21,5 W |
Opslagmedia
Opslagmedia-type | Flash |
---|---|
Totale opslagcapaciteit | 256 GB |
Flash memory | 64000 MB |
Prestatie
Warmtedissipatie | 73,32 BTU/h |
---|---|
Certificering | Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to- SonicWall VPN, SCEP, FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSM |
Minimale systeemeisen
Compatibele besturingssystemen | Microsoft Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Windows 10, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE, Apple iOS, Mac OS X, Google Android, Kindle Fire, Chrome, Windows 8.1 (Embedded) |
---|
Eisen aan de omgeving
Temperatuur, in bedrijf | 0 - 40 °C |
---|---|
Temperatuur bij opslag | -40 - 70 °C |
Relatieve luchtvochtigheid, in bedrijf | 5 - 95 procent |
Luchtvochtigheid bij opslag | 5 - 95 procent |
Gewicht en omvang
Gewicht | 4 kg |
---|---|
Breedte | 430 mm |
Diepte | 325 mm |
Hoogte | 45 mm |
Inhoud van de verpakking
Meegeleverde software | Secure Upgrade Plus - Advanced Edition 3Y |
---|
Overige specificaties
Autenticatiemethode | LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database,Terminal Services, Citrix, Common Access Card (CAC) |
---|
Technische details
Code geharmoniseerd systeem (HS) | 85176990 |
---|
Logistieke gegevens
Aantal per verpakking | 1 stuk(s) |
---|
