Supermicro MBD-X11SDV-8C-TP8F-O moederbord Systeem op een chip (SOC) Flex-ATX

Supermicro MBD-X11SDV-8C-TP8F-O, Intel, Intel® Xeon®, DDR4-SDRAM, 768 GB, 1.2 V, 2133,2400,2666 MHz

Nog 1 beschikbaar (bel voor reservering)

Fabrikant Super Micro
MPN MBD-X11SDV-8C-TP8F-O
EAN 0672042323548
€ 1.563,00 excl. BTW

Supermicro MBD-X11SDV-8C-TP8F-O moederbord Systeem op een chip (SOC) Flex-ATX

Supermicro motherboard advantages:

- Technologically-advanced Motherboard Designs Since 1993
- Consistent highest-quality Design, Components, and Production Expertise
- Extensive Range of x86 Serverboards Available
- Competitive Price/Performance
- High Performance Boards Supporting the Latest CPU, memory, and add-on Hardware
- Standard Form Factors offer Feature-rich Support and application optimization
These competitive advantages help Supermicro maintain its design leadership in providing state-of-the-art motherboards for a wide range of applications. Always a step ahead of the competition, Supermicro is consistently first-to-market in delivering high-performance technology support. Offering the most extensive serverboard selection in the industry at competitive prices, Supermicro boards are quality-built to maximize customer satisfaction.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Processor

Processorfabrikant*
Intel
Compatibele processors*
Intel® Xeon®
Processor aantal cores ondersteund
8

Geheugen

Ondersteunde geheugen types*
DDR4-SDRAM
Geheugen voltage
1.2 V
ECC
Ja
Supported memory clock speeds
2133,2400,2666 MHz
Maximum intern geheugen*
768 GB
Maximum UDIMM geheugen
256 GB

Opslag-controllers

Ondersteunde opslagstationinterfaces*
SATA III
RAID support
Ja
Soorten RAID
0, 1, 5, 10

Grafisch

On-board graphics adapter model
Aspeed AST2500

Interne aansluitingen

Aantal SATA III connectors*
4
Aansluitingen voor behuizingsventilatoren
5
COM aansluitingen
1

Aansluitingen achterzijde

Aantal USB 2.0-poorten*
2
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A*
2
Aantal Ethernet LAN (RJ-45)-poorten*
6
VGA (D-Sub)poort(en)*
1
Aantal COM-poorten
1

Netwerk

Ethernet LAN
Ja
Ethernet interface type
Gigabit Ethernet
Wifi*
Nee

Kenmerken

Chipset moederbord*
Systeem op een chip (SOC)
PC gezondheids monitor
Ventilator, LED, Temperatuur, Spanning
Moederbord form factor*
Flex-ATX

Uitbreidingsmodules

PCI Express x16 (Gen 3.x) slots
1

BIOS

BIOS type*
UEFI
Grootte BIOS-geheugen
128 Mbit
Plug and play
Ja

Processor speciale functies

Trusted Platform Module (TPM)
Ja

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 60 °C
Relatieve vochtigheid in bedrijf (V-V)
8 - 90 procent
Luchtvochtigheid bij opslag
5 - 95 procent

Logistieke gegevens

Code geharmoniseerd systeem (HS)
84733020

Gewicht en omvang

Breedte
228,6 mm
Diepte
184,2 mm

Inhoud van de verpakking

Meegeleverde software
IPMI2.0, KVM with dedicated LAN, Watchdog

Overige specificaties

PCI Express x8 (Gen 3.x) slots
1
Ondersteunend DIMM module capaciteiten
16GB, 32GB, 64GB, 128MB
Ondersteunde LRDIMM module capciteit
16GB, 32GB, 64GB
Ondersteunde LRDIMM kloksnelheden
2133,2400 MHz
Maximum LRDIMM geheugen
512 GB
Ondersteunende RDIMM klok snelheden
2133,2400,2666 MHz
Ondersteunende UDIMM module capaciteit
16GB, 32GB, 64GB
Aantal DIMM sloten
4
Aantal ondersteunde processoren
1
Thermal Design Power (TDP)
80 W

Technische details

Vormfactor
Flex ATX
Duurzaamheidscertificaten
RoHS
