Synology FS6400, 2,1 GHz, 4110, 32 GB, DDR4-SDRAM, 800 W, Desktop

Nog slechts 8 beschikbaar

Fabrikant Synology
MPN FS6400
EAN 4711174722730

Synology FS6400 server Desktop Intel® Xeon® 4110 2,1 GHz 32 GB DDR4-SDRAM 800 W Windows Server 2016 Standard

Uncompromising performance
Synology FlashStation FS6400 is a 2U rackmount server designed for I/O-intensive and latency-sensitive tasks, ideal for multimedia post-production, virtual machines, online transaction processing, or database applications.

Fast and reliable networking
With multi-LAN design, FS6400 is capable of performing Link Aggregation and failover. For environments requiring a higher speed, two optional Ethernet add-in cards can be installed on PCIe 3.0 slots to provide fast data transmission.

Complete iSCSI and virtualization solutions
Synology iSCSI storage supports most virtualization solutions such as VMware vSphere, Microsoft Hyper-V, Citrix Xen Server, and OpenStack Cinder to enhance work efficiency. You can run and manage multiple virtual machines on Windows, Linux, or DSM using Virtual Machine Manager.

Next-generation file system for better data protection
The Btrfs file system introduces advanced storage technologies and optimized snapshots to prevent data corruption and reduce maintenance overheads. It offers flexible, efficient data protection and recovery tools while ensuring high-level data integrity.

Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders

Snapshot Replication provides schedulable and storage capacity-saving data protection with 1,024 shared folder backups and 65,000 system-wide snapshots

File- or folder-level data restoration accelerates data recovery and provides more flexibility for businesses

Automatic file self-healing detects and recovers corrupted files without user intervention

RAID F1
Due to the peculiarities of SSD and RAID technology, a common challenge lies in how to prevent all of the drives from failing at the same time because of the evenly distributed workload. RAID F1 alleviates this problem with a specially designed algorithm to unevenly distribute workload to drives, enhancing the resilience of the storage pool and ensuring your data remains safe.

Digital asset protection
Powered by Synology DiskStation Manager (DSM), Synology NAS offers advanced security measures to protect against sudden data loss and potential security holes. Learn more

Security Advisor
Analyze system settings, password strength and network preferences, and remove any possible malware.

AppArmor
A kernel-level enhancement that blocks malicious programs from accessing unauthorized system resources.

AES 256-bit encryption
ncrypt shared folders and network data transmission to avoid unauthorized data access.

2-step verification
Prevent others from logging in to your DSM by generating a six-digit one-time password (OTP) on your mobile device.

Trust level
Customize the trust level in Package Center to avoid installing packages from untrusted sources, safeguarding your NAS from unknown or tampered package files.

5-year warranty
As we're committed to improving product innovation and quality, Synology guarantees a robust and reliable data management experience with a 5-year limited warranty, providing responsive technical support and hardware replacement services to maximize your return on investment.

Synology Replacement Service (SRS)
SRS provides free advance replacement units as early as the next business day in selected regions, maximizing the service uptime for your mission-critical storage and ensuring your business continuity.

Powered by Synology DSM

Synology High Availability
Seamless transition between clustered servers in the event of a server failure to minimize the impact on applications.

Synology Office
Collaborate on documents, spreadsheets, and slides in real time to boost team productivity.

Synology MailPlus
Secure, reliable, and private mail server solution with an intuitive and modern mail client.

Virtual Machine Manager
Run various operating systems in isolated sandboxes. Seamlessly clone, restore and migrate virtual machines.

Security
Comprehensive built-in security tools are constantly updated to protect your devices against evolving threats.

Snapshot Replication
Schedulable and instantaneous data protection for shared folders and iSCSI LUNs for disaster prevention.
  • Synology all-flash server targeted at I/O-intensive and
  • latency-sensitive applications
  • Over 240,000 iSCSI 4K Random Write IOPS, ultra-high
  • performance with low latency1
  • Dual Intel Xeon Silver 8-core processors and 32GB
  • DDR4 ECC RDIMM, expandable up to 512GB
  • Onboard 10GBASE-T ports, capable of installing
  • optional 10GbE/25GbE/40GbE NICs
  • Complete virtualization solution for VMware vSphere
  • Windows Server Hyper-V, Citrix XenServer, and
  • OpenStack Cinder
  • Advanced Btrfs file system offering 65,000 system-wide
  • snapshots and 1,024 snapshots per shared folder
  • Scale up to 72 drives with 2 x Synology expansion unit
  • RX2417sas2

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Processor

Processorfabrikant*
Intel
Processorfamilie*
Intel® Xeon®
Processorgeneratie
1e generatie Intel® Xeon® schaalbaar
Processormodel*
4110
Frequentie van processor*
2,1 GHz
Maximale turbofrequentie van processor
3 GHz
Aantal processorkernen
8
Processor cache
11 MB
Aantal geïnstalleerde processoren
2
Thermal Design Power (TDP)
85 W
Processor cache type
L3
Processor socket
LGA 3647 (Socket P)
Processor lithografie
14 nm
Processor aantal threads
16
Processor operating modes
64-bit
Codenaam processor
Skylake
Tcase
77 °C
Maximaal intern geheugen ondersteund door processor
768 GB
Geheugentypen ondersteund door processor
LPDDR4-SDRAM
Klokgeheugen-snelheden ondersteund door processor
2400 MHz
Execute Disable Bit
Ja
Maximaal aantal PCI Express-lijnen
48
Verpakkingsgrootte processor
76.0 x 56.5 mm
Ondersteunde instructie sets
AVX, AVX 2.0, AVX-512, SSE4.2
Schaalbaarheid
2S
Ingebouwde opties beschikbaar
Ja
Conflictvrije processor
Ja

Geheugen

Intern geheugen*
32 GB
Intern geheugentype*
DDR4-SDRAM
Maximaal intern geheugen
512000 MB
Geheugenslots
16
Maximum intern geheugen*
512 GB

Opslagmedia

Maximale opslagcapaciteit*
552,96 TB
HDD interface
SATA
HDD omvang
2.5"
Aantal geïnstalleerde SSD's
24
SSD capaciteit
184,32 GB
SSD interfaces
E-SATA
RAID support*
Ja
Soorten RAID
0, 1, 5, 6, 10, JBOD
Hot-swap
Ja
Soort optische drive*
Nee

Netwerk

Ondersteunde netwerkprotocollen
CIFS, AFP, NFS, FTP, WebDAV
Wake-on-LAN
Ja
Ethernet LAN
Ja
Bekabelingstechnologie
10/100/1000Base-T(X)

Poorten & interfaces

Aantal Ethernet LAN (RJ-45)-poorten*
2
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A
2

Uitbreidingsmodules

PCI Express x8 (Gen 3.x) slots
2
PCI Express slots versie
3.0

Design

Type behuizing*
Desktop
Kleur van het product
Zwart

Prestatie

Geluidsniveau
53,7 dB

Software

Inclusief besturingssysteem*
Windows Server 2016 Standard
Compatibele besturingssystemen*
Windows Server 2016

Processor speciale functies

Enhanced Intel SpeedStep Technology
Ja
Intel® Virtualization Technology for Directed I/O (VT-d)
Ja
Intel® Hyper Threading Technology (Intel® HT Technology)
Ja
Intel® Turbo Boost Technology
2.0
Intel® AES New Instructions (Intel® AES-NI)
Ja
Intel® Trusted Execution Technology
Ja
Intel® VT-x with Extended Page Tables (EPT)
Ja
Intel® TSX-NI
Ja
Intel® 64
Ja
Intel® Virtualization Technology (VT-x)
Ja
Versie Intel® TSX-NI
1,00
ARK ID processor
123547

Energie

Aantal voedingen
1
Stroomvoorziening
100 - 240
Redundante voeding*
Ja
Netvoeding*
800 W
Aantal geïnstalleerde redundante voedingen
1
Ingangsfrequentie voeding
50 - 60 Hz
Stroomverbruik (typisch)
288,49 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 35 °C
Temperatuur bij opslag
-20 - 60 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 95 procent

Certificaten

Certificering
EAC, VCCI, RCM, KC, FCC, CE, BSMI

Logistieke gegevens

Code geharmoniseerd systeem (HS)
84714100

Gewicht en omvang

Breedte
482 mm
Diepte
724 mm
Hoogte
88 mm
Gewicht
17,3 kg

Inhoud van de verpakking

Meegeleverde kabels
AC

Overige specificaties

Stroomverbruik (in standby)
145,8 W
Ventilator(en)
80 x 80mm x4
Aantal gebruikers
6000 gebruiker(s)
