Dedicated In Network Centralized Management
The OC200 Omada Cloud Controller delicate to provide centralized management for the whole Omada network. Monitor statistics in real-time, view a graphical analysis of network traffic, create a captive portal, upgrade and reboot your system, and easily scale your network to boost your business.
Free Cloud Management – Anywhere, Anytime
Omada offers free cloud access to its centralized management platform. Take your network with you, wherever you go.
Industry Leading Hardware Design
Equipped with an advanced hardware design and the latest chipset, OC200 has the impressive processing power to support the massive management of your business network.
Guest Network with Facebook Wi-Fi and SMS Login
Visitors have access to secure Wi-Fi with captive portal and wireless isolation technology. Newly added SMS authentication simplifies the connection process, while Facebook authentication raises the social media profile of your business.
Even More Convenient with Omada App
Remotely access and configure the OC200 from the convenience of your smartphone, wherever you are in the world.
The OC200 Omada Cloud Controller delicate to provide centralized management for the whole Omada network. Monitor statistics in real-time, view a graphical analysis of network traffic, create a captive portal, upgrade and reboot your system, and easily scale your network to boost your business.
Free Cloud Management – Anywhere, Anytime
Omada offers free cloud access to its centralized management platform. Take your network with you, wherever you go.
Industry Leading Hardware Design
Equipped with an advanced hardware design and the latest chipset, OC200 has the impressive processing power to support the massive management of your business network.
Guest Network with Facebook Wi-Fi and SMS Login
Visitors have access to secure Wi-Fi with captive portal and wireless isolation technology. Newly added SMS authentication simplifies the connection process, while Facebook authentication raises the social media profile of your business.
Even More Convenient with Omada App
Remotely access and configure the OC200 from the convenience of your smartphone, wherever you are in the world.
- LED-indicatoren
- Type processor
- MAC adres filtering
- Web-gebaseerd management
- Reset button
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten. Meld fout
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten. Meld fout
Design
Kleur van het product*
Zwart
LED-indicatoren
Ja
Kabelslot sleuf type
Kensington
Kenmerken
Soort antenne
Intern
Prestatie
Besturings -en afbeeldingseenheid*
Nee
Type processor
Ja
Frequentie van processor
1200 MHz
Aantal geïnstalleerde processoren
1
Intern geheugen
1024 MB
Intern geheugentype
DDR3
Flash memory
4000 MB
Netwerk
Ethernet LAN, data-overdrachtsnelheden
10,100 Mbit/s
Netwerkstandaard
IEEE 802.3af, IEEE 802.3at
Beveiliging
Access Control List (ACL)
Ja
MAC adres filtering
Ja
Ondersteunde beveiligingsalgoritmen
SSID, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
VLAN=ondersteuning
Ja
Poorten & interfaces
Aantal USB 2.0-poorten
1
Aantal Ethernet LAN (RJ-45)-poorten
2
Beheerfuncties
Web-gebaseerd management
Ja
Quality of Service (QoS)
Ja
Reset button
Ja
Energie
Vermogensverbruik (max)
11,3 W
Power over Ethernet (PoE)
Ja
Gewicht en omvang
Breedte
100 mm
Diepte
98 mm
Hoogte
25 mm
Inhoud van de verpakking
Meegeleverde kabels
LAN (RJ-45)
Snelle installatiehandleiding
Ja
Eisen aan de omgeving
Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent
Luchtvochtigheid bij opslag
5 - 90 procent
Certificaten
Certificering
CE, FCC, RoHS
Logistieke gegevens
Code geharmoniseerd systeem (HS)
85176990
