TP-Link TL-SF1016D Unmanaged Fast Ethernet (10/100) Wit

TP-Link TL-SF1016D, Unmanaged, Fast Ethernet (10/100), Full duplex, Ophangsysteem voor aan de muur

Ruim op voorraad

MPN TL-SF1016D
EAN 6935364020293
€ 57,00 excl. BTW

TP-Link TL-SF1016D Unmanaged Fast Ethernet (10/100) Wit

What This Product Does
The TL-SF1016D Fast Ethernet Switch is designed for SOHO (Small Office/Home Office) or workgroup users. All 16 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SF1016D can save the power consumption and 70% of the packaging material can be recycled, making it an eco-friendly solution for your business network.

High Performance
TL-SF1016D Fast Ethernet Switch provides 16 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. Featuring non-blocking switching architecture, TL-SF1016D forwards and filters packets at full wire-speed for maximum throughput. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the traffic congestion and make TL-SF1016D work reliably.

TP-LINK Green Technology
This new generation TL-SF1016D Fast Ethernet Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.

It also complies with the EU’S RoHS, prohibiting the use of certain hazardous materials. Besides, 70% of the packaging material can be recycled.

Easy to Use
The auto features of this switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100 Mbps) and intelligently adjusts for compatibility and optimal performance.
  • 16 10/100Mbps Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX
  • Green Ethernet technology saves power consumption
  • IEEE 802.3x flow control provides reliable data transfer
  • Plastic case, desktop or wall-mounting design
  • Plug and play, no configuration required

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Unmanaged

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
16
Type basis-switching RJ-45 Ethernet-poorten*
Fast Ethernet (10/100)
Netstekker
DC-in ingang

Netwerk

Netwerkstandaard*
IEEE 802.3u, IEEE 802.3x
10G support*
Nee
Koperen ethernetbekabelingstechnologie
100BASE-TX, 10BASE-T
Full duplex
Ja
Half-duplex
Ja
Datastroombeheer
Ja
Auto MDI/MDI-X
Ja
Auto-negotiation
Ja
MAC-adres zelflerende functie
Ja

Data-uitwisseling

Ondersteunde data-overdrachtsnelheden
10/100 Mbps
Switchingcapaciteit*
3,2 Gbit/s
MAC-adrestabel*
2000 entries
Store-and-forward
Ja
Max. overdrachtssnelheid
0,1 Gbit/s

Protocollen

Ondersteunde netwerkprotocollen
CSMA/CD, TCP/IP

Design

Kleur van het product
Wit
Ophangsysteem voor aan de muur
Ja
Certificering
FCC, CE

Energie

Stroombron*
DC
Vermogenstoevoer inclusief*
Ja
Stroom
0.6 A
Ingangsspanning
5 V
Vermogensverbruik (max)
3,23 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Nee

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Temperatuur bij opslag
-40 - 60 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent
Luchtvochtigheid bij opslag
5 - 95 procent
Warmtedissipatie
7,03 BTU/h

Gewicht en omvang

Breedte
200,9 mm
Diepte
142,5 mm
Hoogte
41 mm

Verpakking

Breedte verpakking
285 mm
Diepte verpakking
223 mm
Hoogte verpakking
68 mm
Gewicht verpakking
570 g

Overige specificaties

Afmetingen (B x D x H)
200 x 142 x 40 mm
Connectiviteitstechnologie
Bedraad
Connectivity LEDs
