Transcend MTE652T2 2.5" 512 GB PCI Express 3.1 3D NAND NVMe

Transcend MTE652T2, 512 GB, 2.5", 2100 MB/s

Niet op voorraad

Fabrikant Transcend
MPN TS512GMTE652T2
EAN 0760557848615
€ 116,00 excl. BTW

Transcend MTE652T2 2.5" 512 GB PCI Express 3.1 3D NAND NVMe

Transcend's MTE652T2 M.2 SSD features the PCI Express (PCIe) Gen 3 x4 interface and is compatible with NVM Express (NVMe) 1.3 specifications, delivering unparalleled transfer speeds. The MTE652T2 features the latest 3D NAND technology for higher storage efficiency, 30µ" PCB gold finger and Corner Bond technology for enhanced durability, built-in DRAM cache for fast access, an extended operating temperature range from -20°C to 75°C, and an endurance rating of 3K Program/Erase cycles for reliable operation.
  • DRAM Cache embedded
  • 30µ" PCB gold finger
  • Endurance: 3K P/E cycles (Program/Erase cycles) guaranteed
  • PCIe Gen 3 x4 interface
  • Key components fortified by default with Corner Bond technology
  • Compliant with PCI Express specification 3.1
  • Compliant with NVM Express specification 1.3
  • Supports NVM command
  • SLC caching technology
  • Built-in LDPC ECC (Error Correction Code) functionality

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Kenmerken

NVMe versie
1.3
SSD-vormfactor*
2.5"
SSD capaciteit*
512 GB
Interface*
PCI Express 3.1
Type geheugen*
3D NAND
NVMe*
Ja
Component voor*
PC
Leessnelheid
2100 MB/s
Schrijfsnelheid
1000 MB/s
Random read (4KB)
190000 IOPS
Random write (4KB)
290000 IOPS
PCI Express interface data lanes
x4
ECC
Ja
Mean time between failures (MTBF)
3000000 uur
Certificering
CE, FCC, BSMI

Energie

Operating voltage
3,3 V

Energie

Slaapstand
0,6 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
-20 - 75 °C
Temperatuur bij opslag
-55 - 85 °C
Minimum operationele temperatuur
-20 °C
Maximale temperatuur (in bedrijf)
75 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 95 procent
Trillingen, in bedrijf
20 G
Schokbestendigheid
1500 G

Technische details

Duurzaamheidscertificaten
RoHS

Gewicht en omvang

Breedte
80 mm
Diepte
3,58 mm
Hoogte
22 mm
Gewicht
9 g
