Productinformatie
Trendnet TPE-P521ES. Switch type: Managed. Type basis-switching RJ-45 Ethernet-poorten: Gigabit Ethernet (10/100/1000), Aantal basis-switching RJ-45 Ethernet-poorten: 5. MAC-adrestabel: 2048 entries, Switchingcapaciteit: 10 Gbit/s. Netwerkstandaard: IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE.... Power over Ethernet (PoE). Ophangsysteem voor aan de muur
5-Port Gigabit PoE+ Powered EdgeSmart Switch with PoE Pass Through, model TPE-P521ES, is powered by a PoE+ switch or injector, no AC adapter is required. It features two gigabit non-PoE ports, and two gigabit PoE ports to power devices such as IP cameras, VoIP handsets, and wireless access points. Reducing unnecessary switch complexity, this EdgeSmart switch is equipped with only the most commonly used managed switch features. The simple web-based user interface allows you to easily manage VLANs, QoS, and monitoring.
Integration Flexibility
Managed features include access control lists, VLAN, IGMP Snooping, and QoS for flexible network integration.
PoE+ Powered
No AC adapter required—this switch is powered by a PoE+ switch or injector, and features two gigabit non-PoE ports, and two gigabit PoE ports to power devices such as IP cameras.
EdgeSmart Management
Provides an easy to use web-based management interface for reduced switch configuration complexity and offers a combination of more commonly used SMB management features for easy deployment.
- 1 x Gigabit PoE+ input port
- 2 x Gigabit PoE output ports
- 2 x Gigabit ports
- 18W PoE power budget
- Easy to use web-based management interface
- Supports LACP, VLAN, QoS, STP, RTSP and IGMP Snooping
- Voice VLAN for VoIP applications
- Bandwidth control per port
- 10Gbps switching capacity
- IEEE 802.1p QoS with queue scheduling support
- Compact fanless design
- Wall mountable metal housing
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
5-Port Gigabit PoE+ Powered EdgeSmart Switch with PoE Pass Through, model TPE-P521ES, is powered by a PoE+ switch or injector, no AC adapter is required. It features two gigabit non-PoE ports, and two gigabit PoE ports to power devices such as IP cameras, VoIP handsets, and wireless access points. Reducing unnecessary switch complexity, this EdgeSmart switch is equipped with only the most commonly used managed switch features. The simple web-based user interface allows you to easily manage VLANs, QoS, and monitoring.
Integration Flexibility
Managed features include access control lists, VLAN, IGMP Snooping, and QoS for flexible network integration.
PoE+ Powered
No AC adapter required—this switch is powered by a PoE+ switch or injector, and features two gigabit non-PoE ports, and two gigabit PoE ports to power devices such as IP cameras.
EdgeSmart Management
Provides an easy to use web-based management interface for reduced switch configuration complexity and offers a combination of more commonly used SMB management features for easy deployment.
- 1 x Gigabit PoE+ input port
- 2 x Gigabit PoE output ports
- 2 x Gigabit ports
- 18W PoE power budget
- Easy to use web-based management interface
- Supports LACP, VLAN, QoS, STP, RTSP and IGMP Snooping
- Voice VLAN for VoIP applications
- Bandwidth control per port
- 10Gbps switching capacity
- IEEE 802.1p QoS with queue scheduling support
- Compact fanless design
- Wall mountable metal housing
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
Specificaties
Ontwerp
| Rack-montage | Nee |
|---|---|
| LED-indicatoren | Ja |
| Certificering | CE, FCC |
| Ophangsysteem voor aan de muur | Ja |
| Kleur van het product | Zwart |
Beheerfuncties
| Switch type | Managed |
|---|---|
| Multicast-ondersteuning | Ja |
| Quality of Service (QoS) | Ja |
| Reset button | Ja |
Poorten & interfaces
| Aantal basis-switching RJ-45 Ethernet-poorten | 5 |
|---|---|
| Type basis-switching RJ-45 Ethernet-poorten | Gigabit Ethernet (10/100/1000) |
Netwerk
| Netwerkstandaard | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x |
|---|---|
| IGMP snooping | Ja |
| 10G support | Nee |
| VLAN=ondersteuning | Ja |
| Port mirroring | Ja |
| Broadcast stormbeheer | Ja |
| Spanning tree protocol | Ja |
| Virtuele LAN-functies | Private VLAN,VLAN Identifier ( VLAN ID),Voice VLAN,Tagged VLAN,Port-based VLAN |
Data-uitwisseling
| MAC-adrestabel | 2048 entries |
|---|---|
| Switchingcapaciteit | 10 Gbit/s |
| Aantal VLANs | 4094 |
| Jumbo Frames ondersteuning | Ja |
| Jumbo frames | 9216 |
| Verzending snelheid | 7,44 Mpps |
Beveiliging
| Bescherming lus | Ja |
|---|
Protocollen
| Beheerprotocollen | SNMP v1, v2c |
|---|
Prestatie
| Upgraden van firmware mogelijk | Ja |
|---|---|
| Mean time between failures (MTBF) | 730455 uur |
| Buffergrootte | 512 KB |
Energie
| Vermogensverbruik (max) | 20,4 W |
|---|
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | Ja |
|---|---|
| Hoeveelheid Power over Ethernet (PoE) ports | 2 |
| Aantal Power over Ethernet plus (PoE +)-poorten | 1 |
| Totaal Power over Ethernet (PoE)-budget | 18 W |
| Stroomspanning bescherming | Overstroom, Kortsluiting |
Eisen aan de omgeving
| Temperatuur, in bedrijf | 0 - 40 °C |
|---|
Gewicht en omvang
| Breedte | 150 mm |
|---|---|
| Diepte | 97 mm |
| Hoogte | 28,6 mm |
| Gewicht | 370 g |
