Trendnet TPE-TG52 netwerk-switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Zwart

Trendnet TPE-TG52, Unmanaged, Gigabit Ethernet (10/100/1000), Gigabit Ethernet, Full duplex, Power over Ethernet (PoE), Ophangsysteem voor aan de muur

Ruim op voorraad

Fabrikant Trendnet
MPN TPE-TG52
EAN 0710931162219
€ 39,00 excl. BTW

Trendnet TPE-TG52 netwerk-switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Zwart

TRENDnet's 5-Port Gigabit PoE+ Switch, model TPE-TG52, reduces equipment and installation costs by delivering data and power over existing Ethernet cables. With PoE technology, users only need one set of cables to deliver both data and power. This compact network switch features four gigabit PoE+ ports and one gigabit port, with a 32W total PoE power budget. The TPE-TG52 PoE+ switch allows you to network PoE devices, such as wireless access points, IP cameras, VoIP phones, IP video encoders, access controls, and more. It features a fanless design, and has a convenient option for wall mounting.

PoE+
A 32W PoE power budget supports up to four Power over Ethernet devices.

Gigabit Ports
Five gigabit ports provide a 10Gbps switching capacity to support edge network installations.

Compact Design
Compact, lightweight, and fanless, this switch is designed for desktops and quiet environments.

Jumbo Frame
Sends Jumbo Frames (up to 9KB) for increased performance

Fanless
Fanless design is ideal for quiet environments that require silent operation
  • Compact fanless design
  • Wall-mountable metal housing

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Unmanaged
Quality of Service (QoS)
Ja

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
5
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Netstekker
DC-in ingang

Netwerk

Netwerkstandaard*
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3p, IEEE 802.3u, IEEE 802.3x
10G support*
Nee
Full duplex
Ja
Half-duplex
Ja
VLAN=ondersteuning
Ja

Optische vezel

Type schakelende optische module
Gigabit Ethernet

Data-uitwisseling

Switchingcapaciteit*
10 Gbit/s
Verzending snelheid
7,44 Mpps
MAC-adrestabel*
2000 entries
Jumbo Frames ondersteuning
Ja
Jumbo frames
9000
Packet buffergeheugen
0,128 MB

Design

Kleur van het product
Zwart
Materiaal behuizing
Metaal
LED-indicatoren
Activiteit, Link, Power over Ethernet (PoE), Stroom
Ophangsysteem voor aan de muur
Ja
Certificering
CE, FCC, LVD

Prestatie

Fanloos
Ja
MTBF (PoE)
3516000 uur

Energie

Stroombron*
AC/DC
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz
DC voltage input
54 V
Stroom
1.2 A
Vermogensverbruik (max)
36 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Ja
Aantal Power over Ethernet plus (PoE +)-poorten
4
Vermogen per poort Power over Ethernet (PoE)
30 W
Totaal Power over Ethernet (PoE)-budget
32 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V)
0 - 90 procent

Gewicht en omvang

Breedte
121 mm
Diepte
75 mm
Hoogte
26 mm
Gewicht
246 g

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
