Zyxel GS1100-24E, Unmanaged, Gigabit Ethernet (10/100/1000), Rack-montage, Ophangsysteem voor aan de muur

Ruim op voorraad

Fabrikant ZyXEL
MPN GS1100-24E-EU0103F
EAN 4718937614127

Zyxel GS1100-24E Unmanaged Gigabit Ethernet (10/100/1000) Zwart

Plug and play connectivity
Simply unbox the GS1100 unmanaged switch, you can enjoy instant plug-n-play Gigabit connectivity without any additional settings required with auto-negotiation and auto MDI/MDI-X. Supporting 802.1p prioritization and jumbo frame, the switch ensures smooth voice and video traffic for your office network.

Whisper quiet operation
The GS1100 Series has fanless design that ensures silent operation in small or quiet office environments. The GS1100-10HP PoE model is specifically designed with an external power adapter that eliminates the need for an additional fan to cool down the device, making it perfect for quiet PoE deployments.

Energy saving
The GS1100 features Energy Efficient Ethernet(IEEE 802.3az) which automatically detects network traffic and adjusts power consumption dynamically. Zyxel’s green features also adjust power consumption by detecting the link status and cable length reducing business operating expenses.

Support PoE+
The GS1100-10HP supports PoE+ (IEEE 802.3at) which provides a maximum of 30W per port, delivering fully automated support for powering compatible IP phones, video surveillance cameras or wireless access points.

Flexible choices for your office
The GS1100 Series switch offers multiple options including 8-port, 16-port, and 24-port for diversified office applications.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Unmanaged

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
24
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)

Netwerk

Netwerkstandaard*
IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support*
Nee
Auto MDI/MDI-X
Ja

Data-uitwisseling

Switchingcapaciteit*
48 Gbit/s
Verzending snelheid
35,7 Mpps
MAC-adrestabel*
8000 entries
Jumbo frames
10000
Packet buffergeheugen
0,525 MB

Design

Rack-montage*
Ja
Kleur van het product
Zwart
LED-indicatoren
Ja
Ophangsysteem voor aan de muur
Ja
Certificering
LVD, BSMI, EMC Class A, CE, FCC, RCM, ICES-003, BSMI, RoHS, REACH

Prestatie

Fanloos
Ja

Prestatie

Mean time between failures (MTBF)
366919 uur

Energie

Vermogenstoevoer inclusief*
Ja
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz
Vermogensverbruik (max)
13 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Nee

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 40 °C
Warmtedissipatie
43,53 BTU/h

Gewicht en omvang

Breedte
267 mm
Diepte
162 mm
Hoogte
42 mm
Gewicht
1,5 kg

Verpakking

Meegeleverde kabels
AC
Rekbevestigingspakket
Ja

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
