Zyxel GS1920-8HPV2, Managed, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Ophangsysteem voor aan de muur

Ruim op voorraad

Fabrikant ZyXEL
MPN GS1920-8HPV2-EU0101F
EAN 4718937602230

Zyxel GS1920-8HPV2 Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Zwart

Advanced smart managed switching
Minimise wasteful overpowering of devices and help your business save money and time whilst powering more devices with the GS1920 series.
Perfect for SMBs these smart managed switches are rich in L2 features and provide 375Watts over
Ethernet providing reliant and future-proof networking.
Zyxel's One Network (ZON) provides a free and easy-to-use tool to simplify configuration, management and troubleshooting of the switch allowing you to focus on your business priorities.
Zyxel's networking equipement comes with in-built 'awareness' of other Zyxel units in your network allowing for one-click remote factory resets and power cycling through Zyxel Smart Connect.

Intuitive web-based interface
Would you like access to L2 features such as LACP, advanced QoS, VLAN, ACL and multicast IGMP snooping, without learning complex command-line interface(CLI)? You can with the intuitive web-based interface.

Connect more devices with consumption mode
Maximise your 375W of total budget and connect more power-hungry devices. 'Consumption mode' allows for delivery of only the actual power required for more efficiency and better ROI for your business.

Hear the silence with Smart Fan
Silent and reliable switch operation ideal for the office environment, both desktop and rack mounted. The in-built smart fan is designed to automatically adjust speed based on device temperature. Smart Fan will be available on current models with a Firmware upgrade from January 2018 (v4.5).

Plug into the power of the Zyxel ONE network
Easily maintain your network in one FREE platform with the Zyxel One Network (ZON) tool. Instal, configure and discover switches, WLAN and gateways in your network with one-click. ZON Utility is a free of charge tool which has been downloaded by over 15,000 users to date.

Maximum flexibility for your Gig
Futureproof your network for growth with the The GS1920 series. Ideal for SMB deployments in multiple scenarios, the GS1920 series provides up to 28 Gigabit copper ports for 24-port models, and up to 6 Gigabit fiber ports for 48-port models.
  • Inbuilt 'awareness' of other zyxel units in your network
  • Web GUI interface for centralised management
  • One-click remote factory resets and power cycling
  • No additional software required

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Quality of Service (QoS)
Ja
ARP-inspectie
Ja
System event log
Ja
MIB-ondersteuning
RFC 1066, RFC 1213, RFC 1157, RFC 1493, RFC 1643, RFC 1757, RFC 2011.2012,2013, RFC 2233, RFC 2358, RFC 2674, RFC 2819,2925, RFC 3621, RFC 4022, RFC 4113, RFC 4292, RFC 4293

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
8
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal Combo SFP-poorten
2
Vezel-optische connector
SFP

Netwerk

Netwerkstandaard*
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support*
Nee
Koperen ethernetbekabelingstechnologie
100BASE-TX, 1000BASE-T
Datastroombeheer
Ja
Rate limiting
Ja
Spanning tree protocol
Ja
VLAN=ondersteuning
Ja
Virtuele LAN-functies
Private VLAN, Voice VLAN, Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN, IP subnet–based VLAN

Optische vezel

Fiber ethernet cabling technologie
1000BASE-X

Data-uitwisseling

Switchingcapaciteit*
20 Gbit/s
Verzending snelheid
15 Mpps
MAC-adrestabel*
16000 entries
Packet buffergeheugen
1,5 MB

Beveiliging

DHCP-functies
DHCP snooping, DHCP relay, DHCPv6 relay, DHCP client
Access Control List (ACL)
Ja
IGMP snooping
Ja
Ondersteunde beveiligingsalgoritmen
802.1x RADIUS, SNMP, SNMPv3
MAC adres filtering
Ja
IP-MAC-Port binding
Ja
Authenticatie
Gast-VLAN, Poortgebaseerde authenticatie
Wachtwoordbeveiliging
Ja
Authenticatie type
IEEE 802.1x, RADIUS
CPU-bescherming
Ja
Algoritmen wachtrijplanning
SPQ, WFQ, Weighted Round Robin (WRR)

Multicast-functies

Multicast-ondersteuning
Ja

Design

Rack-montage*
Nee
Kleur van het product
Zwart
LED-indicatoren
Ja
Ophangsysteem voor aan de muur
Ja
Veiligheid
LVD, BSMI
Elektromagnetische compatibiliteit
FCC 15 A, CE A, BSMI EMC
Certificering
RoHS

Prestatie

Intern geheugen
256 MB
Flash memory
32 MB
Mean time between failures (MTBF)
513985 uur

Energie

AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz
Vermogensverbruik (max)
161,8 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Ja
Hoeveelheid Power over Ethernet (PoE) ports
8
Totaal Power over Ethernet (PoE)-budget
130 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 50 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 95 procent
Luchtvochtigheid bij opslag
10 - 95 procent
Warmtedissipatie
551,74 BTU/h

Gewicht en omvang

Breedte
267 mm
Diepte
162 mm
Hoogte
44 mm
Gewicht
1,9 kg

Verpakking

Meegeleverde kabels
AC
Breedte verpakking
375 mm
Diepte verpakking
235 mm
Hoogte verpakking
61 mm
Gewicht verpakking
2,73 kg

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
