Zyxel XGS2210-52, Managed, L2, Gigabit Ethernet (10/100/1000), Rack-montage, 1U

Ruim op voorraad

Fabrikant ZyXEL
MPN XGS2210-52-EU0101F
EAN 4718937587902

Zyxel XGS2210-52 Managed L2 Gigabit Ethernet (10/100/1000) 1U Zwart

Agile traffic control for converged networking applications

ZyXEL XGS2210/GS2210 Series has a rich Layer 2 feature set that can shape the traffic for diverse VoIP, video conference, IPTV and IP surveillance deployments and provide hotels, businesses andeducational institutions greater agility and more effective traffic management for the converged applications of today.

ZyXEL One Network experience

Aiming for relieving our customers from repetitive operations of deploying and managing a network, ZyXEL One Network is designed to simplify the configuration, management, and troubleshooting, allowing our customers to focus on the business priorities. ZyXEL One Network presents an easy-to-use tool, ZyXEL One Network Utility (ZON Utility), to realize speed network setup. ZyXEL Smart Connect allows ZyXEL networking equipment to be aware and recognize each other and further facilitating the network maintenance via one-click remote functions such as factory reset or power cycling. ZyXEL One Network redefines the network integration across multiple networking products from switch to Wi-Fi AP and to Gateway.

High-powered Power over Ethernet (PoE)

The ZyXEL XGS2210/GS2210 Series PoE switches support the IEEE 802.3af PoE and 802.3at PoE Plus standards, which provide up to 30 watts of power per port for advanced Powered Devices (PD) like 802.11ac wireless APs and video IP phones. The high power budget enables the XGS2210/GS2210 PoE switches to comfortably accommodate the PDs required in a modern network edge.

High-powered Power over Ethernet (PoE)

The ZyXEL XGS2210/GS2210 Series PoE switches support the IEEE 802.3af PoE and 802.3at PoE Plus standards, which provide up to 30 watts of power per port for advanced Powered Devices (PD) like 802.11ac wireless APs and video IP phones. The high power budget enables the XGS2210/GS2210 PoE switches to comfortably accommodate the PDs required in a modern network edge.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Switch-laag
L2
Quality of Service (QoS)
Ja
Web-gebaseerd management
Ja
Traffic shaping
Ja
ARP-inspectie
Ja
System event log
Ja
MIB-ondersteuning
RFC 1066, RFC 1213, RFC 1493, RFC 1643, RFC 1757, RFC 2011, RFC 2233, RFC 2358, RFC 2674, RFC 2819, RFC 2925, RFC 3621, RFC 4022, RFC 4113, RFC 4292, RFC 4293

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
48
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal moduleslots SPF+
4

Netwerk

Netwerkstandaard*
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support*
Ja
Port mirroring
Ja
IP routing
Ja
Datastroombeheer
Ja
Verbindingsaggregatie
Ja
Broadcast stormbeheer
Ja
Rate limiting
Ja
Spanning tree protocol
Ja
MAC-adres zelflerende functie
Ja
VLAN=ondersteuning
Ja
Virtuele LAN-functies
Private VLAN, Protocol-based VLAN, Port-based VLAN

Data-uitwisseling

Switchingcapaciteit*
176 Gbit/s
Throughput
130,9 Mpps
MAC-adrestabel*
16000 entries
Aantal wachtrijen
8
Jumbo Frames ondersteuning
Ja
Jumbo frames
9000
Packet buffergeheugen
1,5 MB

Beveiliging

DHCP-functies
DHCP client
Access Control List (ACL)
Ja
IGMP snooping
Ja
Ondersteunde beveiligingsalgoritmen
802.1x RADIUS, SNMP, SSH, SSH-2
MAC adres filtering
Ja
SSH/SSL support
Ja
BPDU filtering / bescherming
Ja
Authenticatie
MAC-gebaseerde authenticatie

Multicast-functies

Multicast-ondersteuning
Ja

Design

Rack-montage*
Ja
Stapelbaar*
Ja
Vormfactor
1U
Kleur van het product
Zwart
Veiligheid
LVD, BSMI
Elektromagnetische compatibiliteit
FCC 15 (A), CE (A), BSMI
Certificering
RoHS

Prestatie

Geluidsniveau
44,15 dB
Plug and play
Ja
Mean time between failures (MTBF)
970594 uur

Energie

AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz
Vermogensverbruik (max)
45 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Nee

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 50 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 95 procent
Luchtvochtigheid bij opslag
10 - 90 procent
Warmtedissipatie
153,3 BTU/h

Gewicht en omvang

Breedte
441 mm
Diepte
270 mm
Hoogte
45 mm
Gewicht
3,86 kg

Verpakking

Meegeleverde kabels
AC
Rekbevestigingspakket
Ja
Breedte verpakking
622 mm
Diepte verpakking
358 mm
Hoogte verpakking
108 mm
Gewicht verpakking
4,92 kg

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
