Zyxel XMG1930-30HP Managed L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U Zwart

Zyxel XMG1930-30HP, Managed, L3, 2.5G Ethernet (100/1000/2500), Power over Ethernet (PoE), Rack-montage, 1U

Niet op voorraad

Fabrikant ZyXEL
MPN XMG1930-30HP-ZZ0101F
EAN 4718937622078
€ 1.629,00 excl. BTW
4,5 · 4,0 · Gratis verzending vanaf €250
Omschrijving
The XMG1930 series is a family of Multi-Gigabit L2 Smart Managed switches including 2 models, with and without PoE options.
On top of its high-density twenty-four 2.5G ports that serve as a top performance access switch to upgrade from standard gigabit network, the switches also offer four 10G Multi-Gigabit ports to expand network connection to WiFi 6/6E AP or 10G servers along with two additional 10G fiber ports for extensibility and resilience. The PoE model XMG1930-30HP supports both PoE+ and PoE++ with a large power budget of 700 W offering great flexibility to deploy WiFi 6/6E and WiFi 7 wireless access points; while the non-PoE model XMG1930-30 is ideal for high-speed Internet Service Providers to upgrade from traditional 1G/2.5G to every user.
  • Multi-Gigabit supports with 2.5G and 10G combinations offering flexibility for high density Multi-Gig deployments
  • Up to Six 10G uplinks including both copper and fiber options providing extensibility and resilience for networks
  • Main ports support up to 2.5G makes the Switch an ideal solution for high-speed Internet Service Providers to upgrade from traditional 1G/2.5G to every user
  • Nebula ecosystem offers a unified cloud network experience, from wired, wireless and security gateway
  • Smart Managed L2 Switch feature set with L3 static route
  • Access and manage the full feature sets included from the first day of purchase through the local web GUI
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten. Meld foutBedankt voor uw melding!

Er ging iets mis. Probeer het opnieuw.

Productassistent

Vraag mij alles over dit product

Onze digitale assistent geeft direct antwoord op je productvragen, maar kan zich soms vergissen.

Specificaties

Beheerfuncties

Switch type
Managed
Switch-laag
L3
Quality of Service (QoS)
Ja
Web-gebaseerd management
Ja
Cloud-beheerd
Ja
Locatie-instellingen (CLI) configureren
Ja
MIB-ondersteuning

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten
24
Type basis-switching RJ-45 Ethernet-poorten
2.5G Ethernet (100/1000/2500)
Aantal 10G Ethernet (koper)poorten
4
Aantal geïnstalleerde SFP+ modules
2
Vezel-optische connector
SFP+
Netstekker
AC-in-aansluiting

Netwerk

Netwerkstandaard
IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3x, IEEE 802.3z
10G support
Ja
Op beleid gebaseerde routering
Ja
Datastroombeheer
Ja
Broadcast stormbeheer
Ja
Rate limiting
Ja
Spanning tree protocol
Ja
Ethernet LAN, data-overdrachtsnelheden
10,100,1000,2500,10000 Mbit/s
VLAN=ondersteuning
Ja
Aantal VLANs
4000

Data-uitwisseling

Switchingcapaciteit
240 Gbit/s
Verzending snelheid
178,5 Mpps
MAC-adrestabel
16000 entries
Statische route
Ja
Jumbo Frames ondersteuning
Ja
Jumbo frames
12000

Beveiliging

DHCP-functies
DHCP client, DHCPv6 relay
Access Control List (ACL)
Ja
IGMP snooping
Ja
MAC adres filtering
Ja
SSH/SSL support
Ja
Bescherming lus
Ja

Multicast-functies

Multicast-ondersteuning
Ja

Protocollen

GARP VLAN Registratieprotocol (GVRP)
Ja

Design

Rack-montage
Ja
Vormfactor
1U
Kleur van het product
Zwart
Reset button
Ja
LED-indicatoren
Ja

Prestatie

Mean time between failures (MTBF)
587922,31 uur

Energie

Stroombron
AC
Vermogenstoevoer inclusief
Ja
AC-ingangsspanning
100 - 240 V
AC-ingangsfrequentie
50 - 60 Hz
Vermogensverbruik (max)
864,1 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Ja
Hoeveelheid Power over Ethernet (PoE) ports
28
Aantal Power over Ethernet plus (PoE +)-poorten
20
Totaal Power over Ethernet (PoE)-budget
700 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
-20 - 50 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 95 procent
Luchtvochtigheid bij opslag
5 - 95 procent
Warmtedissipatie
864,1 BTU/h

Gewicht en omvang

Breedte
441 mm
Diepte
330 mm
Hoogte
44 mm
Gewicht
4,85 kg

Inhoud van de verpakking

Meegeleverde kabels
AC
Rekbevestigingspakket
Ja
