Productinformatie
Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.
Specificaties
Ontwerp
Type behuizing | Rack (2U) |
---|---|
Overtollige fans ondersteuning | Ja |
Soort optische drive | Nee |
Rack-montage | Ja |
Processor speciale functies
Enhanced Intel SpeedStep Technology | Ja |
---|---|
Intel® VT-x with Extended Page Tables (EPT) | Ja |
Intel® TSX-NI | Ja |
Intel® Trusted Execution Technology | Ja |
Intel® 64 | Ja |
Intel® Virtualization Technology for Directed I/O (VT-d) | Ja |
Intel® Virtualization Technology (VT-x) | Ja |
Intel® AES New Instructions (Intel® AES-NI) | Ja |
Intel® Hyper Threading Technology (Intel® HT Technology) | Ja |
Intel® Turbo Boost Technology | 2.0 |
ARK ID processor | 193385 |
Processor
Kloksnelheid processor | Nee |
---|---|
Processorfamilie | Intel Xeon Silver |
Processormodel | 4214 |
Aantal processorkernen | 12 |
Aantal geïnstalleerde processoren | 1 |
Processorfabrikant | Intel |
Processor socket | LGA 3647 (Socket P) |
Frequentie van processor | 2,2 GHz |
Maximale turbofrequentie van processor | 3,2 GHz |
Processor cache | 16,5 MB |
Ingebouwde opties beschikbaar | Ja |
Processor operating modes | 64-bit |
Execute Disable Bit | Ja |
Thermal Design Power (TDP) | 85 W |
Codenaam processor | Cascade Lake |
Schaalbaarheid | 2S |
Processor lithografie | 14 nm |
Ondersteunde instructie sets | AVX-512 |
Tcase | 77 °C |
Processor aantal threads | 24 |
Processor cache type | Smart Cache |
Maximaal intern geheugen ondersteund door processor | 1024 GB |
Maximaal aantal PCI Express-lijnen | 48 |
Geheugentypen ondersteund door processor | DDR4-SDRAM |
Klokgeheugen-snelheden ondersteund door processor | 2400 MHz |
Verpakkingsgrootte processor | 76.0 x 56.5 mm |
Frequentie van processor | 2,2 GHz |
Processorgeneratie | 2e generatie Intel® Xeon® schaalbaar |
Opslagmedia
RAID support | Ja |
---|---|
Soorten RAID | 0, 1, 5, 10 |
Harde schijf, omvang | 2.5" |
Harde schijf-interface | SATA, Serial Attached SCSI (SAS) |
Maximum aantal HDD's per behuizing | 12 |
Supported hard disk drive sizes | 3.5" |
Geheugen
Maximum intern geheugen | 768 GB |
---|---|
Intern geheugen | 16 GB |
Intern geheugentype | DDR4-SDRAM |
Kloksnelheid geheugen | 2933 MHz |
Geheugenslots | 24x DIMM |
Type gebufferd geheugen | Registered (buffered) |
Maximum intern geheugen | 768 GB |
Grafisch
On-board graphics adapter model | Niet beschikbaar |
---|---|
On-board graphics adapter model | Niet beschikbaar |
Netwerk
Bekabelingstechnologie | 10/100/1000Base-T(X) |
---|---|
Ethernet interface type | Gigabit Ethernet |
LAN controller | HP 331i |
Ethernet LAN | Ja |
Poorten & interfaces
Aantal DisplayPorts | 1 |
---|---|
Aantal Ethernet LAN (RJ-45)-poorten | 4 |
Aantal poorten USB 3.0 (3.1 Gen 1) Type A | 3 |
Aantal poorten USB 3.0 (3.1 Gen 1) Type A | 3 |
Uitbreidingsmodules
PCI Express slots versie | 3.0 |
---|
Technische details
Duurzaamheidscertificaten | ENERGY STAR |
---|
Prestatie
Inclusief besturingssysteem | Nee |
---|---|
Compatibele besturingssystemen | Windows Server 2019 |
Code geharmoniseerd systeem (HS) | 84714100 |
Energie
Redundante voeding | Ja |
---|---|
Aantal hoofdvoedingen | 1 |
Voeding | 800 W |
Gewicht en omvang
Breedte | 445,5 mm |
---|---|
Hoogte | 87,4 mm |
Diepte | 730,3 mm |
Gewicht | 14,8 kg |
Certificaten
Energy Star-certificaat | Ja |
---|---|
Energy Star-certificaat | Ja |
