LevelOne GEP-0823 netwerk-switch Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Zwart

LevelOne GEP-0823, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE)

Ruim op voorraad

Fabrikant LevelOne
MPN GEP-0823
EAN 4015867207444
€ 99,00 excl. BTW

LevelOne GEP-0823 netwerk-switch Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Zwart

The LevelOne GEP-0823 is an 8-port Gigabit Ethernet PoE switch that provides Power over Ethernet on all eight of its ports. Per PoE port a power supply of up to 30W is possible. The total PoE power budget is 120W. It is the ideal solution when office and home users are using a combination of PoE and non-PoE devices.

The GEP-0823\'s eight PoE-enabled ports make it an ideal solution for office users who use PoE-enabled devices and already want to power a larger number of PoE devices. These products can be a mix of PoE IP phones, PoE Wifi APs and PoE IP cams. It is the perfect solution for offices that want to upgrade their office equipment and LAN infrastructure to PoE capability or upgrade their existing PoE infrastructure to Gigabit speed. The switch automatically detects the connected IEEE 802.3at/af standard device and provides these devices with power and data over a single cable.

The GEP-0823 also enables users to provide a stable and reliable high-speed LAN environment with store-and-forward switching architecture, packet error filtering and blockade-free packet forwarding. The 802.3x flow control mechanisms operate in both full and half duplex modes. This switch also supports the N-Way auto negotiation protocol, which automatically detects network speed and duplex mode.

For instant fault detection, the GEP-0823 is equipped with a complete set of LEDs to help monitor and troubleshoot the network.
  • IEEE 802.3af/at PoE compliant to simplify deployment and installation
  • 10/100/1000Mbps wire speed transmission and reception
  • Auto-detection and protection of non-standard PoE devices
  • IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
  • Total PoE power budget: 120W, up to 30W per port

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
8
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Netstekker
DC-in ingang

Netwerk

Netwerkstandaard*
IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
10G support*
Nee
Koperen ethernetbekabelingstechnologie
10BASE-T, 100BASE-TX, 1000BASE-T
Full duplex
Ja

Data-uitwisseling

Switchingcapaciteit*
16 Gbit/s
MAC-adrestabel*
8000 entries
Store-and-forward
Ja
Jumbo Frames ondersteuning
Ja
Jumbo frames
9126

Design

Stapelbaar*
Nee
Kleur van het product
Zwart
Materiaal behuizing
Metaal
LED-indicatoren
Activiteit, LAN, Stroom
Land van herkomst
China
Certificering
CE,FCC

Prestatie

Intern geheugen
1 MB
Buffergrootte
8 KB
Mean time between failures (MTBF)
30000 uur

Energie

Stroom
2.5 A
Ingangsspanning
52 V

Energie

Stroomverbruik (typisch)
10 W
Stroomspanning bescherming
Overstroom, Kortsluiting

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Ja
Hoeveelheid Power over Ethernet (PoE) ports
8
Vermogen per poort Power over Ethernet (PoE)
30 W
Totaal Power over Ethernet (PoE)-budget
120 W

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
-20 - 70 °C
Temperatuur bij opslag
-20 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
5 - 90 procent
Luchtvochtigheid bij opslag
5 - 90 procent

Gewicht en omvang

Breedte
86 mm
Diepte
30 mm
Hoogte
176 mm
Gewicht
450 g

Verpakking

Snelstartgids
Ja
Inclusief AC-adapter
Ja
Breedte verpakking
230 mm
Diepte verpakking
60 mm
Hoogte verpakking
290 mm
Gewicht verpakking
950 g
