LevelOne GES-2216 netwerk-switch Managed L2 Gigabit Ethernet (10/100/1000) Zwart

LevelOne GES-2216, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Rack-montage

Ruim op voorraad

Fabrikant LevelOne
MPN GES-2216
EAN 4015867229989
€ 89,00 excl. BTW

LevelOne GES-2216 netwerk-switch Managed L2 Gigabit Ethernet (10/100/1000) Zwart

If you're in search of a networking solution that fits your 10-inch rack/enclosure, the LevelOne GES-2216 Hilbert gigabit smart lite switch is an excellent option. This next-generation Ethernet switch delivers better functionality and usability, making it cost-effective for businesses and organizations.

The switch offers 16 (10M/100M/1G) RJ45 ports and is compatible with the latest LevelOne IP Locator, the easiest-to-use switch discovery tool, which can search all Hilbert series switches and instantly know forgotten IP and other info. Additionally, it's compatible with mainstream Windows and Mac operating systems.

With both dumb and smart Switchable usage modes, the switch is easily configurable using a DIP switch. It provides high-speed connectivity for all your devices, with 16 Gigabit ports. The support for 802.1q VLAN allows you to segment your network for enhanced security and performance.

The switch supports Port Mirroring, which allows you to monitor network traffic in real-time. Additionally, with Port-Based/802.1p/DSCP priority QoS and support for Storm Control, you can prioritize network traffic correctly and ensure that your network remains secure.

The advanced features like Loop Detection/Prevention make sure your network is always safe and reliable. Moreover, the web-based user interface and Smart-Configuration Utility make IP configuration a breeze. Upgrade your networking today with this powerful switch, and enjoy the ultimate performance, security, and ease of use.
  • 16 Gigabit Ethernet ports
  • 1000Mbps full-duplex, 10/100Mbps full/half-duplex, auto-negotiation, auto-MDI/MDIX
  • Supports 8K MAC address auto-learning and auto-aging
  • 10K jumbo frames to increase data transfer rates
  • IP Multicast Filtering through IGMP Snooping V1 / V2
  • 802.1Q tag-based VLAN allows network segmentation to enhance performance and security
  • IEEE 802.1p QoS with 4 priority queues
  • Supports unknown unicast / broadcast / multicast storm control
  • Minimize carbon footprint with advanced energy efficient technology (IEEE 802.3az)
  • 4KV surge protection, 6KV contact / 8KV air ESD protection
  • Support Dumb and Web Smart two mode by dip switches
  • Web-based and smart lite Management
  • Supports LevelOne IP Locator for easier IP management

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Switch-laag
L2
Quality of Service (QoS)
Ja
Web-gebaseerd management
Ja

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
16
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal Gigabit Ethernet (koper)-poorten
16
Netstekker
AC-in-aansluiting

Netwerk

Netwerkstandaard*
IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support*
Nee
Port mirroring
Ja
Full duplex
Ja
Half-duplex
Ja
Verbindingsaggregatie
Ja
Broadcast stormbeheer
Ja
Rate limiting
Ja
Auto MDI/MDI-X
Ja
Auto-negotiation
Ja
MAC-adres zelflerende functie
Ja
MAC-adres zelfverouderende functie
Ja
VLAN=ondersteuning
Ja
Aantal VLANs
32

Data-uitwisseling

Switchingcapaciteit*
32 Gbit/s
Verzending snelheid
23808 Mpps
MAC-adrestabel*
8000 entries
Jumbo Frames ondersteuning
Ja
Jumbo frames
10000
Packet buffergeheugen
4,1 MB

Beveiliging

IGMP snooping
Ja

Design

Rack-montage*
Ja

Design

Stapelbaar*
Nee
Kleur van het product
Zwart
LED-indicatoren
Activiteit, Link, Stroom
Certificering
CE, UKCA, FCC Part 15, Subpart B Class B, RoHS

Prestatie

Flash memory
2 MB
Fanloos
Ja
Mean time between failures (MTBF)
43800 uur

Energie

Stroombron*
AC
Vermogenstoevoer inclusief*
Ja
Stroomverbruik (typisch)
6 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Nee

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 45 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent
Luchtvochtigheid bij opslag
5 - 95 procent
Warmtedissipatie
35,8 BTU/h

Gewicht en omvang

Breedte
215 mm
Diepte
150 mm
Hoogte
44,5 mm
Gewicht
838 g

Verpakking

Meegeleverde kabels
AC
Snelstartgids
Ja
Type verpakking
Doos
Rekbevestigingspakket
Ja
Breedte verpakking
285 mm
Diepte verpakking
257 mm
Hoogte verpakking
62 mm
Gewicht verpakking
1,27 kg
