HPE 5130-24G-SFP-4SFP+ EI, Managed, L3, Rack-montage, 1U

Bel of chat voor info

Fabrikant HP
MPN JG933A#ABB
EAN 0888182606803

HPE 5130-24G-SFP-4SFP+ EI Managed L3 1U Zwart

The HP 5130 EI Switch Series delivers flexibility, scalability and low TCO at the access layer of medium and large enterprise campus networks. Offering enterprise class QoS and security, HP Intelligent Resilient Framework (IRF) stacking, static layer 3 routing and RIP, convenient fixed 10GbE uplink ports, PoE+, ACLs, IPv6 and delivers energy savings with Energy Efficient Ethernet.

The HP 5130 EI Switch Series is SDN ready with OpenFlow 1.3 support, can be managed with HP Intelligent Management Center (IMC) for a single view of your entire network, and includes Lifetime Warranty 2.0.

Scalable and Flexible Access Layer Switches

• The HP 5130 EI Switch Series delivers flexibility, scalability and low TCO at the access layer of medium- and large-enterprise campus networks. The 5130 supports stacking, fixed 10GbE ports, static layer 3 routing and RIP v1/v2, PoE+, ACLs, IPv6 and power savings with Energy Efficient Ethernet.


Improved Quality of Service with Traffic Management

• The HP 5130 EI Switch Series supports advanced classifier-based QoS which groups traffic using multiple match criteria based on Layer 2 and 3 information; applies QoS policies such as setting priority level and rate limit to selected traffic on a port, VLAN, or whole switch.


Comprehensive Security Control

• The HP 5130 EI Switch Series supports flexible authentication methods including 802.1X and MAC Authentication for greater security and policy-driven application authentication.
Per-user access control lists (ACLs) provide identity-driven security and access control.


Single View of the Network

• The HP 5130 EI Switch Series can be seamlessly managed with HP Intelligent Management Center (IMC) to provide end-to-end network transparency with consistent network experience through comprehensive configuration, compliance and policy management.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Switch-laag
L3
Quality of Service (QoS)
Ja

Poorten & interfaces

Aantal moduleslots SPF
24
Aantal moduleslots SPF+
4
Console port
RJ-45

Netwerk

Netwerkstandaard*
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
10G support*
Nee
IP routing
Ja
Datastroombeheer
Ja
Verbindingsaggregatie
Ja
Broadcast stormbeheer
Ja
Spanning tree protocol
Ja
VLAN=ondersteuning
Ja

Data-uitwisseling

Switchingcapaciteit*
128 Gbit/s
Throughput
96 Mpps
MAC-adrestabel*
16384 entries
Latentie (1 Gbps)
5 µs
Latentie (10 Gbps)
1,5 µs
Packet buffergeheugen
1,5 MB

Beveiliging

DHCP-functies
DHCP server, DHCP client
Access Control List (ACL)
Ja
IGMP snooping
Ja

Multicast-functies

Multicast-ondersteuning
Ja

Design

Rack-montage*
Ja
Vormfactor
1U
Kleur van het product
Zwart

Prestatie

Type geheugen
SDRAM
Intern geheugen
1024 MB
Flash memory
128 MB
Geluidsniveau
50,7 dB

Energie

Vermogenstoevoer inclusief*
Nee

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Nee

Eisen aan de omgeving

Bedrijfstemperatuur (T-T)
0 - 45 °C
Temperatuur bij opslag
-40 - 70 °C
Relatieve vochtigheid in bedrijf (V-V)
10 - 90 procent
Luchtvochtigheid bij opslag
5 - 95 procent
Warmtedissipatie
204 BTU/h

Gewicht en omvang

Breedte
440 mm
Diepte
360 mm
Hoogte
43,6 mm
Gewicht
8 kg

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
