Hewlett Packard Enterprise R8M25A netwerk-switch Managed L3 Gigabit Ethernet (10/100/1000)

Hewlett Packard Enterprise R8M25A, Managed, L3, Gigabit Ethernet (10/100/1000), Rack-montage

Bel of chat voor info

Fabrikant HP
MPN R8M25A
EAN 0190017526072
€ 5.697,00 excl. BTW

Hewlett Packard Enterprise R8M25A netwerk-switch Managed L3 Gigabit Ethernet (10/100/1000)

Powerful Performance
The HPE FlexNetwork 5520 HI Switch series provides medium and large enterprise networks with increased processing power, Larger MAC size tables, and Longest Prefix Match (LPM) to improve network performance and scalability by enabling multipathing.

Highly Resilient and Scalable Access Layer Switches
The HPE FlexNetwork 5520 HI Switch series uses Intelligent Resilient Framework (IRF) that supports virtualization of up to nine physical switches into one logical device for simpler, flatter, and more agile networks.

Robust Quality of Service (QoS)
The HPE FlexNetwork 5520 HI Switch Series supports advanced classifier-based QoS which groups traffic using multiple match criteria based on Layer 2 and 3 information, it applies QoS policies such as setting priority level and rate limit to selected traffic on a port, VLAN, or the entire switch.

Disclaimer
Beat-it.nl is niet verantwoordelijk voor eventuele fouten in de documentatie van producten.

Specificaties

Beheerfuncties

Switch type*
Managed
Switch-laag
L3
Quality of Service (QoS)
Ja

Poorten & interfaces

Aantal basis-switching RJ-45 Ethernet-poorten*
24
Type basis-switching RJ-45 Ethernet-poorten*
Gigabit Ethernet (10/100/1000)
Aantal moduleslots SPF
4

Netwerk

10G support*
Ja

Data-uitwisseling

Switchingcapaciteit*
288 Gbit/s
Throughput
180 Mpps
Latentie (1 Gbps)
5 µs
Latentie (10 Gbps)
3 µs
Packet buffergeheugen
4 MB

Design

Rack-montage*
Ja
Stapelbaar*
Ja
Aantal ventilatoren
2 ventilator(en)

Prestatie

Type geheugen
SDRAM
Intern geheugen
2000 MB
Flash memory
512 MB

Energie

Vermogenstoevoer inclusief*
Ja
AC-ingangsspanning
90 - 264 V
DC voltage input
36 - 72 V
Vermogensverbruik (max)
150 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)*
Nee

Eisen aan de omgeving

Warmtedissipatie
324 BTU/h

Gewicht en omvang

Breedte
440 mm
Diepte
360 mm
Hoogte
43,6 mm
Gewicht
6,7 kg

Logistieke gegevens

Code geharmoniseerd systeem (HS)
85176990
